12 x 24 Victor 1224AH-3 Hydraulic Surface Grinder

12 x 24 Victor 1224AH-3 Surface Grinder

Brand: Victor
Model: 1224AH-3
Serial Number: 703228-1
HP: 3
Volts: 220
Table size: 12" x 24"
Max. table travel: 13" x 27"
Max. surface ground: 12" x 24"
Max. distance from spindle center to table: 20"
Chuck size: 12" x 24" (Electromagnetic chuck)
Grinding Wheel Size: 14" x 1.5" x 5"
Spindle Wheel Speed: 1750RPM
Over the Wheel Dresser

Operational & Technical Specifications

• Table & Cross Feed: Table speeds range from 200" – 1,000" / min on V & Flat Turcite ways, with a power cross feed of 44" / min and auto cross feed increments of 0.004" – 0.8".
• Down Feed: Features a vertical handwheel feed of 0.0001" per graduation and 0.05" per revolution, alongside auto down feed options on applicable models.
• Grinding Wheel & Spindle: Utilizes a 14" x 1.5" x 5" max wheel size running at a spindle speed of 1,750 RPM.
• Power Motors: Driven by a 3 HP spindle motor, 1 HP hydraulic pump motor, 1/5 HP cross feed/elevation motors, and a 1/8 HP coolant pump.
• Weight & Dimensions: Features an approximate net weight of 3,740 lbs and shipping dimensions of 90" x 71" x 83".

Specifications subject to verification.
