SANDVIK COROMANT - R840-0480-30-A0A - DC=4.80mm DRILL
Have one to sell?
$39.00 USD
ConditionNew
1 available
New
SANDVIK COROMANT - R840-0480-30-A0A - DC=4.80mm DRILL
Cutting diameter: 0.189 inch
Connection diameter machine side: 0.2362 inch
Usable length: 0.5984 inch
Achievable hole tolerance: H9
Usable length diameter ratio: 3.1667
Orthogonal rake angle: 21.61 degrees
Face effective cutting-edge count: 2
Point angle: 140 °
Point length: 0.0315 inch
Overall length: 2.5984 inch
Functional length: 2.5669 inch
Chip flute length: 1.1024 inch
