Sandvik T-Max L566.4FGC-323222-16

Sandvik T-Max L566.4FGC-323222-16 U-Lock head for thread turning

NEW IN BOX

Part 2 of cutting item interface identifiers (CUTINTMASTER)U-Lock -external size 16 (L166.0G-16)

Axial clearance angle (ALP) -10 deg
Thread helix correction angle (THCA) 1 deg
Adaptive interface machine direction (ADINTMS)SL head (screw mounted) -size 32
Maximum overhang (OHX) 32 mm
Hand (HAND) LEFT
Coolant entry style code (CNSC) 1: axial concentric entry
Coolant pressure (CP) 10 bar
Connection diameter (DCON) 32 mm
Functional length (LF) 32 mm
Functional width (WF) 22 mm
Functional height (HF) 0 mm
Torque (TQ) 1.7 Nm
Weight of item (WT) 0.015 kg
Damping property (DPC) False
Life cycle state (LCS) Not replenished
