13/19 x 40 Acer Dynamic 1340G Precision Gap Bed Lathe w/DRO, Taper, Inch/Metric

13”/19" x 40” Acer Dynamic 1340G Precision Gap Bed Lathe w/DRO, Taper, Inch/Metric
Model: Dynamic 1340G
Swing over Bed: 13"
Swing over Gap: 19 1/4"
Distance between Centers: 40"
Bed Length: 54"
Bed Width: 7 1/2"
Width of Gap: 7 5/8"
System: Inch w/Metric Change Gears
Headstock:
Spindle Bore Diameter: 1 1/2"
Spindle Nose: D1-4
Spindle Speeds: 80 - 2,000 RPM (9 steps)
Spindle Motor: 3 HP-230V 3 Phase
Precision Taper Roller Bearings: Equipped
Hardened and Ground Gears: Precision ground gears in headstock
Tailstock:
Diameter: 1 7/16"
Taper: MT #3
Carriage:
Cross Slide Travel: 6 7/8"
Compound Rest Travel: 4"
Other features:
Leadscrew: Oil lubricated
Gearbox: Universal two-lever gearbox
Apron: Equipped with handwheel on the left side of the carriage
Bed ways: Hardened and ground
Safety: Built-in safety overload friction clutch
Chip pan: Removable type
Foot Brake
Follow Rest & Steady Rest
Sony Digital Read Out
Taper Attachment
8” 4 Jaw Chuck
6” 3 Jaw Chuck
10” Face Plate
