Bridgeport EZ Trak DX Vertical Mill w/Rebuilt 2 HP Head, New Controller, Updated
Have one to sell?
$16,250.00 USD
ConditionUsed
1 available
This Bridgeport EZ Trak DX Vertical Mill has a rebuilt 2 HP Head, many new parts such as controller, USB, Servo PDB, motherboard, and static hard drive. This Bridgeport is ready to serve you for years to come.
Bridgeport Series 1 EZ Trak DX Vertical Mill,
Rebuilt 2HP Variable Speed Head (Top Half & Bottom Half)
New Power Drawbar, (Servo Brand)
R8 Spindle,
Chrome Ways,
New Control Box
New Led Screen,
New Keypad,
New Mother Board,
New Static Hard Drive,
New USB Drive,
Auto Lube System,
Table size: 9" x 48"
Longitudinal travel: 33.5"
Cross travel: 12"
Vertical travel of knee: 14"
Quill travel: 5"
Spindle speeds: 60 to 4200 RPM (infinitely variable)
Spindle quill feeds: 0.0015" – 0.003" – 0.006"
Ram travel: 12"
Positioning speed (X-Y axis): 100 inch / minute
Feed rate range (X-Y axis): 0.1 to 100 inch / minute
Throat: 6-3/4" to 18-3/4"
Distance table to spindle nose: 2-1/2" to 18-1/4"
Motor: 2 HP/1735 RPM
Volts: 230/460 Currently wired for 230V 3 phase
Phase: 3
Cycles: 60
Full load amps: 6.2/3.1
Approximate dimensions: 70" x 77" x 87" high
Approximate weight: 3,000 lbs.
